Register Listing
A-286 ADSP-214xx SHARC Processor Hardware Reference
SRU2_PBEN1 0x1C21 SRU2 Pin Enable 1 0x0021 03CE
SRU2_PBEN2 0x1C22 SRU2 Pin Enable 2 0x0018 5964
DAI Shift Registers
SRU_CLK_SHREG 0x24F1 SRU Shift Register Clock Control 0x0000 0272
SRU_DAT_SHREG 0x24F2 SRU Shift Register Data Control 0x0000 0012
DAI Interrupt Registers
DAI_IMASK_FE 0x2480 DAI Falling Edge Interrupt Mask 0x0
DAI_IMASK_RE 0x2481 DAI Rising Edge Interrupt Mask 0x0
DAI_IRPTL_PRI 0x2484 DAI Interrupt Latch Priority 0x0
DAI_IRPTL_H 0x2488 DAI High Priority Interrupt Latch 0x0
DAI_IRPTL_L 0x2489 DAI Low Priority Interrupt Latch 0x0
DAI_IRPTL_HS 0x248C Shadow DAI High Priority Interrupt Latch 0x0
DAI_IRPTL_LS 0x248D Shadow DTDMAI Low Priority Interrupt Latch 0x0
DPI Interrupt Registers
DPI_IRPTL 0x1C32 DPI Interrupt Latch 0x0
DPI_IRPTL_SH 0x1C33 DPI Shadow Priority Latch 0x0
DPI_IMASK_FE 0x1C34 DPI Falling Edge Interrupt Mask 0x0
DPI_IMASK_RE 0x1C35 DPI Rising Edge Interrupt Mask 0x0
DAI/DPI Pin Buffer Status Registers
DAI_PIN_STAT 0x24B9 DAI Pin Status 0x000F FFFF
DPI_PIN_STAT 0x1C31 DPI Pin Status 0x0000 3FFF
Input Data Port Registers
IDP_CTL0 0x24B0 IDP Control 0 0x0
IDP_CTL1 0x24B2 IDP Control 1 0x0000 FFFF
IDP_CTL2 0x24B3 IDP Control 2 0x0
IDP_PP_CTL 0x24B1 Parallel Data Acquisition Port Control Register 0x0
IDP_FIFO 0x24D0 IDP FIFO Packing Mode 0x0
Register Mnemonic Address Description Reset
