ADSP-214xx SHARC Processor Hardware Reference A-285
Registers Reference
SRU_FS0 0x2450 SRU FS Control 0 0x2736 B4E3
SRU_FS1 0x2451 SRU FS Control 1 0x3DEF 7BDE
SRU_FS2 0x2452 SRU FS Control 2 0x3DEF 7BDE
SRU_FS3 0x2453 SRU FS Control 3 0x1EF7BDE
SRU_FS4 0x2454 SRU FS Control 4 0x3DE
SRU_PIN0 0x2460 SRU Pin Control 0 0x04C8 0A94
SRU_PIN1 0x2461 SRU Pin Control 1 0x04E8 4B96
SRU_PIN2 0x2462 SRU Pin Control 2 0x0366 8C98
SRU_PIN3 0x2463 SRU Pin Control 3 0x03A7 14A3
SRU_PIN4 0x2464 SRU Pin Control 4 0x0569 4F9E
SRU_EXT_MISCA 0x2470 SRU External Misc. A Control 0x3DEF 7BDE
SRU_EXT_MISCB 0x2471 SRU External Misc. B Control 0x3DEF 7BDE
SRU_PBEN0 0x2478 SRU Pin Enable 0 0x0E24 82CA
SRU_PBEN1 0x2479 SRU Pin Enable 1 0x1348 D30F
SRU_PBEN2 0x247A SRU Pin Enable 2 0x1A55 45D6
SRU_PBEN3 0x247B SRU Pin Enable 3 0x1D71 F79B
SRU2 DPI Routing Registers
SRU2_INPUT0 0x1C00 SRU2 Input Signal Routing 0 0x0002 1462
SRU2_INPUT1 0x1C01 SRU2 Input Signal Routing 1 0x1AC0 2C00
SRU2_INPUT2 0x1C02 SRU2 Input Signal Routing 2 0x0
SRU2_INPUT3 0x1C03 SRU2 Input Signal Routing 3 0x0
SRU2_INPUT4 0x1C04 SRU2 Input Signal Routing 4 0x0
SRU2_INPUT5 0x1C05 SRU2 Input Signal Routing 5 0x0
SRU2_PIN0 0x1C10 SRU2 Pin Assignment 0 0x1801 7556
SRU2_PIN1 0x1C11 SRU2 Pin Assignment 1 0x004D B699
SRU2_PIN2 0x1C12 SRU2 Pin Assignment 2 0x0045 0000
SRU2_PBEN0 0x1C20 SRU2 Pin Enable 0 0x0D00 C28B
Register Mnemonic Address Description Reset
