Register Listing
A-304 ADSP-214xx SHARC Processor Hardware Reference
MLB_LCBCR28 0x41BC Channel 28 Local Channel Buffer Control 0x0040 001C
MLB_CECR29 0x4184 Channel 29 Control 0x0
MLB_CSCR29 0x4185 Channel 29 Status 0x8000 0000
MLB_CCBCR29 0x4186 Channel 29 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR29 0x4187 Channel 29 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR29 0x41BD Channel 29 Local Channel Buffer Control 0x0040 001D
MLB_CECR30 0x4188 Channel 30 Control 0x0
MLB_CSCR30 0x4189 Channel 30 Status 0x8000 0000
MLB_CCBCR30 0x418A Channel 30 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR30 0x418B Channel 30 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR30 0x41BE Channel 30 Local Channel Buffer Control 0x0040 001E
Shift Register Register
SR_CTL 0x24F0 Shift Register Control 0x0
Watchdog Timer Registers
WDTCTL 0x5400 Watchdog Timer Control 0x0
WDTCURCNT 0x5401 Watchdog Timer Current Count 0x0
WDTTRIP 0x5402 Watchdog Timer Trip 0x0
WDTCNT 0x5403 Watchdog Timer Count 0x0
WDTSTATUS 0x5404 Watchdog Timer Status 0x0
WDTUNLOCK 0x5405 Watchdog Timer Unlock 0x0
WDTCLKSEL 0x5408 Watchdog Timer Clock Select 0x0
Real-Time Clock Registers
RTC_CLOCK 0x4CA0 Real-Time Clock Clock Undefined
RTC_ALARM 0x4CA1 Real-Time Clock Alarm Undefined
RTC_CTL 0x4CA2 Real-Time Clock Control 0x0
RTC_STAT 0x4CA3 Real-Time Clock Status 0x0
RTC_STPWTCH 0x4CA4 Real-Time Clock Stopwatch Undefined
Register Mnemonic Address Description Reset
