ADSP-214xx SHARC Processor Hardware Reference A-303
Registers Reference
MLB_CCBCR23 0x416E Channel 23 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR23 0x416F Channel 23 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR23 0x41B7 Channel 23 Local Channel Buffer Control 0x0040 0017
MLB_CECR24 0x4170 Channel 24 Control 0x0
MLB_CSCR24 0x4171 Channel 24 Status 0x8000 0000
MLB_CCBCR24 0x4172 Channel 24 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR24 0x4173 Channel 24 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR24 0x41B8 Channel 24 Local Channel Buffer Control 0x0040 0018
MLB_CECR25 0x4174 Channel 25 Control 0x0
MLB_CSCR25 0x4175 Channel 25 Status 0x8000 0000
MLB_CCBCR25 0x4176 Channel 25 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR25 0x4177 Channel 25 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR25 0x41B9 Channel 25 Local Channel Buffer Control 0x0040 0019
MLB_CECR26 0x4178 Channel 26 Control 0x0
MLB_CSCR26 0x4179 Channel 26 Status 0x8000 0000
MLB_CCBCR26 0x417A Channel 26 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR26 0x417B Channel 26 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR26 0x41BA Channel 26 Local Channel Buffer Control 0x0040 001A
MLB_CECR27 0x417C Channel 27 Control 0x0
MLB_CSCR27 0x417D Channel 27 Status 0x8000 0000
MLB_CCBCR27 0x417E Channel 27 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR27 0x417F Channel 27 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR27 0x41BB Channel 27 Local Channel Buffer Control 0x0040 001B
MLB_CECR28 0x4180 Channel 28 Control 0x0
MLB_CSCR28 0x4181 Channel 28 Status 0x8000 0000
MLB_CCBCR28 0x4182 Channel 28 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR28 0x4183 Channel 28 Next Buffer (TX Buffer in I/O Mode) 0x0
Register Mnemonic Address Description Reset
