Register Listing
A-302 ADSP-214xx SHARC Processor Hardware Reference
MLB_CECR18 0x4158 Channel 18 Control 0x0
MLB_CSCR18 0x4159 Channel 18 Status 0x8000 0000
MLB_CCBCR18 0x415A Channel 18 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR18 0x415B Channel 18 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR18 0x41B2 Channel 18 Local Channel Buffer Control 0x0040 0012
MLB_CECR19 0x415C Channel 19 Control 0x0
MLB_CSCR19 0x415D Channel 19 Status 0x8000 0000
MLB_CCBCR19 0x415E Channel 19 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR19 0x415F Channel 19 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR19 0x41B3 Channel 19 Local Channel Buffer Control 0x0040 0013
MLB_CECR20 0x4160 Channel 20 Control 0x0
MLB_CSCR20 0x4161 Channel 20 Status 0x8000 0000
MLB_CCBCR20 0x4162 Channel 20 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR20 0x4163 Channel 20 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR20 0x41B4 Channel 20 Local Channel Buffer Control 0x0040 0014
MLB_CECR21 0x4164 Channel 21 Control 0x0
MLB_CSCR21 0x4165 Channel 21 Status 0x8000 0000
MLB_CCBCR21 0x4166 Channel 21 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR21 0x4167 Channel 21 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR21 0x41B5 Channel 21 Local Channel Buffer Control 0x0040 0015
MLB_CECR22 0x4168 Channel 22 Control 0x0
MLB_CSCR22 0x4169 Channel 22 Status 0x8000 0000
MLB_CCBCR22 0x416A Channel 22 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR22 0x416B Channel 22 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR22 0x41B6 Channel 22 Local Channel Buffer Control 0x0040 0016
MLB_CECR23 0x416C Channel 23 Control 0x0
MLB_CSCR23 0x416D Channel 23 Status 0x8000 0000
Register Mnemonic Address Description Reset
