ADSP-214xx SHARC Processor Hardware Reference A-301
Registers Reference
MLB_CNBCR12 0x4143 Channel 12 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR12 0x41AC Channel 12 Local Channel Buffer Control 0x0040 000C
MLB_CECR13 0x4144 Channel 13 Control 0x0
MLB_CSCR13 0x4145 Channel 13 Status 0x8000 0000
MLB_CCBCR13 0x4146 Channel 13 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR13 0x4147 Channel 13 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR13 0x41AD Channel 13 Local Channel Buffer Control 0x0040 000D
MLB_CECR14 0x4148 Channel 14 Control 0x0
MLB_CSCR14 0x4149 Channel 14 Status 0x8000 0000
MLB_CCBCR14 0x414A Channel 14 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR14 0x414B Channel 14 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR14 0x41AE Channel 14 Local Channel Buffer Control 0x0040 000E
MLB_CECR15 0x414C Channel 15 Control 0x0
MLB_CSCR15 0x414D Channel 15 Status 0x8000 0000
MLB_CCBCR15 0x414E Channel 15 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR15 0x414F Channel 15 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR15 0x41AF Channel 15 Local Channel Buffer Control 0x0040 000F
MLB_CECR16 0x4150 Channel 16 Control 0x0
MLB_CSCR16 0x4151 Channel 16 Status 0x8000 0000
MLB_CCBCR16 0x4152 Channel 16 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR16 0x4153 Channel 16 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR16 0x41B0 Channel 16 Local Channel Buffer Control 0x0040 0010
MLB_CECR17 0x4154 Channel 17 Control 0x0
MLB_CSCR17 0x4155 Channel 17 Status 0x8000 0000
MLB_CCBCR17 0x4156 Channel 17 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR17 0x4157 Channel 17 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR17 0x41B1 Channel 17 Local Channel Buffer Control 0x0040 0011
Register Mnemonic Address Description Reset
