Register Listing
A-300 ADSP-214xx SHARC Processor Hardware Reference
MLB_CSCR7 0x412D Channel 7 Status 0x8000 0000
MLB_CCBCR7 0x412E Channel 7 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR7 0x412F Channel 7 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR7 0x41A7 Channel 7 Local Channel Buffer Control 0x0040 0007
MLB_CECR8 0x4130 Channel 8 Control 0x0
MLB_CSCR8 0x4131 Channel 8 Status 0x8000 0000
MLB_CCBCR8 0x4132 Channel 8 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR8 0x4133 Channel 8 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR8 0x41A8 Channel 8 Local Channel Buffer Control 0x0040 0008
MLB_CECR9 0x4134 Channel 9 Control 0x0
MLB_CSCR9 0x4135 Channel 9 Status 0x8000 0000
MLB_CCBCR9 0x4136 Channel 9 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR9 0x4137 Channel 9 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR9 0x41A9 Channel 9 Local Channel Buffer Control 0x0040 0009
MLB_CECR10 0x4138 Channel 10 Control 0x0
MLB_CSCR10 0x4139 Channel 10 Status 0x8000 0000
MLB_CCBCR10 0x413A Channel 10 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR10 0x413B Channel 10 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR10 0x41AA Channel 10 Local Channel Buffer Control 0x0040 000A
MLB_CECR11 0x413C Channel 11 Control 0x0
MLB_CSCR11 0x413D Channel 11 Status 0x8000 0000
MLB_CCBCR11 0x413E Channel 11 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR11 0x413F Channel 11 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR11 0x41AB Channel 11 Local Channel Buffer Control 0x0040 000B
MLB_CECR12 0x4140 Channel 12 Control 0x0
MLB_CSCR12 0x4141 Channel 12 Status 0x8000 0000
MLB_CCBCR12 0x4142 Channel 12 Current Buffer (RX Buffer in I/O Mode) 0x0
Register Mnemonic Address Description Reset
