ADSP-214xx SHARC Processor Hardware Reference A-299
Registers Reference
MLB_LCBCR1 0x41A1 Channel 1 Local Channel Buffer Control 0x0040 0001
MLB_CECR2 0x4118 Channel 2 Control 0x0
MLB_CSCR2 0x4119 Channel 2 Status 0x8000 0000
MLB_CCBCR2 0x411A Channel 2 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR2 0x411B Channel 2 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR2 0x41A2 Channel 2 Local Channel Buffer Control 0x0040 0002
MLB_CECR3 0x411C Channel 3 Control 0x0
MLB_CSCR3 0x411D Channel 3 Status 0x8000 0000
MLB_CCBCR3 0x411E Channel 3 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR3 0x411F Channel 3 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR3 0x41A3 Channel 3 Local Channel Buffer Control 0x0040 0003
MLB_CECR4 0x4120 Channel 4 Control 0x0
MLB_CSCR4 0x4121 Channel 4 Status 0x8000 0000
MLB_CCBCR4 0x4122 Channel 4 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR4 0x4123 Channel 4 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR4 0x41A4 Channel 4 Local Channel Buffer Control 0x0040 0004
MLB_CECR5 0x4124 Channel 5 Control 0x0
MLB_CSCR5 0x4125 Channel 5 Status 0x8000 0000
MLB_CCBCR5 0x4126 Channel 5 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR5 0x4127 Channel 5 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR5 0x41A5 Channel 5 Local Channel Buffer Control 0x0040 0005
MLB_CECR6 0x4128 Channel 6 Control 0x0
MLB_CSCR6 0x4129 Channel 6 Status 0x8000 0000
MLB_CCBCR6 0x412A Channel 6 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR6 0x412B Channel 6 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR6 0x41A6 Channel 6 Local Channel Buffer Control 0x0040 0006
MLB_CECR7 0x412C Channel 7 Control 0x0
Register Mnemonic Address Description Reset
