Register Listing
A-298 ADSP-214xx SHARC Processor Hardware Reference
RXLB1_OUT_
SHADOW
0x4C2A Link Port 1 Shadow Output RX Buffer 0x0
LSTAT1_
SHADOW
0x4C23 Link Port 1 Shadow Status 0x0
IILB1 0x4C38 Link Port 1 Internal Index 0x0
IMLB1 0x4C39 Link Port 1 Internal Modifier 0x0
CLB1 0x4C3A Link Port 1 Internal Count 0x0
CPLB1 0x4C3B Link Port 1 Chain Pointer 0x0
MLB Registers
MLB_DCCR 0x4100 MLB Device Control 0x0
MLB_SSCR 0x4101 MLB System Status Configuration 0x0
MLB_SDCR 0x4102 System Data Configuration 0x0
MLB_SMCR 0x4103 System Interrupt Mask 0x00000060
MLB_VCCR 0x4107 Version Control Config (Contains the IP Version) 0x202
MLB_SBCR 0x4108 Synchronous Base Address 0x0
MLB_ABCR 0x4109 Asynchronous Base Address 0x0
MLB_CBCR 0x410A Control Base Address 0x0
MLB_IBCR 0x410B Isochronous Base Address 0x0
MLB_CICR 0x410C Channel Interrupt Status 0x0
MLB_CECR0 0x4110 Channel 0 Control 0x0
MLB_CSCR0 0x4111 Channel 0 Status 0x8000 0000
MLB_CCBCR0 0x4112 Channel 0 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR0 0x4113 Channel 0 Next Buffer (TX Buffer in I/O Mode) 0x0
MLB_LCBCR0 0x41A0 Channel 0 Local Channel Buffer Control 0x0040 0000
MLB_CECR1 0x4114 Channel 1 Control 0x0
MLB_CSCR1 0x4115 Channel 1 Status 0x8000 0000
MLB_CCBCR1 0x4116 Channel 1 Current Buffer (RX Buffer in I/O Mode) 0x0
MLB_CNBCR1 0x4117 Channel 1 Next Buffer (TX Buffer in I/O Mode) 0x0
Register Mnemonic Address Description Reset
