ADSP-214xx SHARC Processor Hardware Reference A-297
Registers Reference
Link Port Registers
LCTL0 0x4C00 Link Port 0 Control 0x0
LSTST0 0x4C01 Link Port 0 Status 0x0
TXLB0 0x4C08 Link Port 0 TX Buffer Undefined
RXLB0 0x4C09 Link Port 0 RX Buffer Undefined
TXLB0_IN_
SHADOW
0x4C0D Link Port 0 Shadow Input TX Buffer 0x0
TXLB0_OUT_
SHADOW
0x4C0C Link Port 0 Shadow Output TX Buffer 0x0
RXLB0_IN_
SHADOW
0x4C0B Link Port 0 Shadow Input RX Buffer 0x0
RXLB0_OUT_
SHADOW
0x4C0A Link Port 0 Shadow Output RX Buffer 0x0
LSTAT0_
SHADOW
0x4C03 Link Port 0 Shadow Status 0x0
IILB0 0x4C18 Link Port 0 Internal Index 0x0
IMLB0 0x4C19 Link Port 0 Internal Modifier 0x0
CLB0 0x4C1A Link Port 0 Internal Count 0x0
CPLB0 0x4C1B Link Port 0 Chain Pointer 0x0
LCTL1 0x4C20 Link Port 1 Control 0x0
LSTST1 0x4C21 Link Port 1 Status 0x0
TXLB1 0x4C28 Link Port 1 TX Buffer Undefined
RXLB1 0x4C29 Link Port 1 RX Buffer Undefined
TXLB1_IN_
SHADOW
0x4C2D Link Port 1 Shadow Input TX Buffer 0x0
TXLB1_OUT_
SHADOW
0x4C2C Link Port 1 Shadow Output TX Buffer 0x0
RXLB1_IN_
SHADOW
0x4C2B Link Port 1 Shadow Input RX Buffer 0x0
Register Mnemonic Address Description Reset
