External Port DMA

3-108 ADSP-214xx SHARC Processor Hardware Reference

Figure 3-24. Scatter DMA (Writes)

DESTINATION INDEX (IIEP)

SOURCE INDEX (EIEP)

DESTINATION BUFFER

SOURCE BUFFER

TAP LIST BUFFER

OFFSET1

TAP LIST POINTER (TPEP)

OFFSET2

OFFSET3

EIEP + OFFSET1

EIEP + OFFSET2

EIEP + OFFSET3

www.BDTIC.com/ADI
