ADSP-214xx SHARC Processor Hardware Reference A-131
Registers Reference
Table A-77. Group C Sources – Frame Sync
Selection Code Source Signal Description (Source Selection)
00000 (0x0) DAI_PB01_O Pin Buffer 1
00001 (0x1) DAI_PB02_O Pin Buffer 2
00010 (0x2) DAI_PB03_O Pin Buffer 3
00011 (0x3) DAI_PB04_O Pin Buffer 4
00100 (0x4) DAI_PB05_O Pin Buffer 5
00101 (0x5) DAI_PB06_O Pin Buffer 6
00110 (0x6) DAI_PB07_O Pin Buffer 7
00111 (0x7) DAI_PB08_O Pin Buffer 8
01000 (0x8) DAI_PB09_O Pin Buffer 9
01001 (0x9) DAI_PB10_O Pin Buffer 10
01010 (0xA) DAI_PB11_O Pin Buffer 11
01011 (0xB) DAI_PB12_O Pin Buffer 12
01100 (0xC) DAI_PB13_O Pin Buffer 13
01101 (0xD) DAI_PB14_O Pin Buffer 14
01110 (0xE) DAI_PB15_O Pin Buffer 15
01111 (0xF) DAI_PB16_O Pin Buffer 16
10000 (0x10) DAI_PB17_O Pin Buffer 17
10001 (0x11) DAI_PB18_O Pin Buffer 18
10010 (0x12) DAI_PB19_O Pin Buffer 19
10011 (0x13) DAI_PB20_O Pin Buffer 20
10100 (0x14) SPORT0_FS_O SPORT 0 Frame Sync
10101 (0x15) SPORT1_FS_O SPORT 1 Frame Sync
10110 (0x16) SPORT2_FS_O SPORT 2 Frame Sync
10111 (0x17) SPORT3_FS_O SPORT 3 Frame Sync
11000 (0x18) SPORT4_FS_O SPORT 4 Frame Sync
11001 (0x19) SPORT5_FS_O SPORT 5 Frame Sync
