Register Listing
A-278 ADSP-214xx SHARC Processor Hardware Reference
MT2CS1 0x406 SPORT 2 TDM TX Select, CH63–32 0x0
MT2CS2 0x407 SPORT 2 TDM TX Select, CH95–64 0x0
MT2CS3 0x408 SPORT 2 TDM TX Select, CH127–96 0x0
MR3CS0 0x409 SPORT 3 TDM RX Select, CH31–0 0x0
MR3CS1 0x40A SPORT 3 TDM RX Select, CH63–32 0x0
MR3CS2 0x40B SPORT 3 TDM RX Select, CH95–64 0x0
MR3CS3 0x40C SPORT 3 TDM RX Select, CH127–96 0x0
MT2CCS0 0x40D SPORT 2 TDM TX Compand Select, CH31–0 0x0
MT2CCS1 0x40E SPORT 2 TDM TX Compand Select, CH63–32 0x0
MT2CCS2 0x40F SPORT 2 TDM TX Compand Select, CH95–64 0x0
MT2CCS3 0x410 SPORT 2 TDM TX Compand Select, CH127–96 0x0
MR3CCS0 0x411 SPORT 3 TDM RX Compand Select, CH31–0 0x0
MR3CCS1 0x412 SPORT 3 TDM RX Compand Select, CH63–32 0x0
MR3CCS2 0x413 SPORT 3 TDM RX Compand Select, CH95–64 0x0
MR3CCS3 0x414 SPORT 3 TDM RX Compand Select, CH127–96 0x0
SPMCTL3 0x417 SPORT 3 TDM Control 0x0
IISP2A 0x440 Internal Memory DMA Address 0x0
IMSP2A 0x441 Internal Memory DMA Access Modifier 0x0
CSP2A 0x442 Contains Number of DMA Transfers Remaining 0x0
CPSP2A 0x443 Points to Next DMA Parameters 0x0
IISP2B 0x444 Internal Memory DMA Address 0x0
IMSP2B 0x445 Internal Memory DMA Access Modifier 0x0
CSP2B 0x446 Contains Number of DMA Transfers Remaining 0x0
CPSP2B 0x447 Points to Next DMA Parameters 0x0
IISP3A 0x448 Internal Memory DMA Address 0x0
IMSP3A 0x449 Internal Memory DMA Access Modifier 0x0
CSP3A 0x44A Contains Number of DMA Transfers Remaining 0x0
Register Mnemonic Address Description Reset
