Register Listing
A-280 ADSP-214xx SHARC Processor Hardware Reference
MR5CS2 0x80B SPORT 5 TDM RX Select, CH95–64 0x0
MR5CS3 0x80C SPORT 5 TDM RX Select, CH127–96 0x0
MT4CCS0 0x80D SPORT 4 TDM TX Compand Select, CH31–0 0x0
MT4CCS1 0x80E SPORT 4 TDM TX Compand Select, CH63–32 0x0
MT4CCS2 0x80F SPORT 4 TDM TX Compand Select, CH95–64 0x0
MT4CCS3 0x810 SPORT 4 TDM TX Compand Select, CH127–96 0x0
MR5CCS0 0x811 SPORT 5 TDM RX Compand Select, CH31–0 0x0
MR5CCS1 0x812 SPORT 5 TDM RX Compand Select, CH63–32 0x0
MR5CCS2 0x813 SPORT 5 TDM RX Compand Select, CH95–64 0x0
MR5CCS3 0x814 SPORT 5 TDM RX Compand Select, CH127–96 0x0
SPMCTL5 0x817 SPORT 5 TDM Control 0x0
IISP4A 0x840 Internal Memory DMA Address 0x0
IMSP4A 0x841 Internal Memory DMA Access Modifier 0x0
CSP4A 0x842 Contains Number of DMA Transfers Remaining 0x0
CPSP4A 0x843 Points to Next DMA Parameters 0x0
IISP4B 0x844 Internal Memory DMA Address 0x0
IMSP4B 0x845 Internal Memory DMA Access Modifier 0x0
CSP4B 0x846 Contains Number of DMA Transfers Remaining 0x0
CPSP4B 0x847 Points to Next DMA Parameters 0x0
IISP5A 0x848 Internal Memory DMA Address 0x0
IMSP5A 0x849 Internal Memory DMA Access Modifier 0x0
CSP5A 0x84A Contains Number of DMA Transfers Remaining 0x0
CPSP5A 0x84B Points to Next DMA Parameters 0x0
IISP5B 0x84C Internal Memory DMA Address 0x0
IMSP5B 0x84D Internal Memory DMA Access Modifier 0x0
CSP5B 0x84E Contains Number of DMA Transfers Remaining 0x0
CPSP5B 0x84F Points to Next DMA Parameters 0x0
Register Mnemonic Address Description Reset
