Register Listing
A-292 ADSP-214xx SHARC Processor Hardware Reference
ICPFFT 0x5315 Input Chain Pointer 0x0
OIFFT 0x5318 Output Index 0x0
OMFFT 0x5319 Output Modifier 0x0
OCFFT 0x531A Output Count 0x0
OLFFT 0x531B Output Length 0x0
OBFFT 0x531C Output Base 0x0
OCPFFT 0x531D Output Chain Pointer 0x0
FFTDMASTAT 0x5320 DMA Status 0x0
FFTSHDMASTAT 0x5321 DMA Shadow Status 0x0
FIR Accelerator Registers
FIRCTL1 0x5000 FIR Global Control 0x0
FIRDMASTAT 0x5001 DMA Status Reg 0x0
FIRMACSTAT 0x5002 MAC Status 0x0
FIRDEBUGCTL 0x5004 Debug Control 0x0
FIRDBGADDR 0x5005 Debug Address 0x0
FIRDBGWRDATA 0x5006 Debug Data Write 0x0
FIRDBGRDDATA 0x5007 Debug Data Read 0x0
FIRCTL2 0x5010 Channel Control 0x0
IIFIR 0x5011 Input Data Index 0x0
IMFIR 0x5012 Input Data Modifier 0x0
ICFIR 0x5013 Input Data Count 0x0
IBFIR 0x5014 Input Data Base 0x0
OIFIR 0x5015 Output Data Index 0x0
OMFIR 0x5016 Output Data Modifier 0x0
OCFIR 0x5017 Output Data Count 0x0
OBFIR 0x5018 Output Data Base 0x0
CIFIR 0x5019 Coefficient Index 0x0
Register Mnemonic Address Description Reset
