ADSP-214xx SHARC Processor Hardware Reference A-293
Registers Reference
CMFIR 0x501A Coefficient Modifier 0x0
CCFIR 0x501B Coefficient Count 0x0
CPFIR 0x501C Chain Pointer 0x0
IIR Accelerator Registers
IIRCTL1 0x5200 IIR Global Control 0x0
IIRDMASTAT 0x5201 DMA Status Reg 0x0
IIRMACSTAT 0x5202 MAC Status 0x0
IIRDEBUGCTL 0x5203 Debug Control 0x0
IIRDBGADDR 0x5204 Debug Address 0x0
IIRDBGWRDATA_L 0x5205 Debug Data Write LS 32 Bits 0x0
IIRDBGWRDATA_H 0x5206 Debug Data Write MS 8 Bits 0x0
IIRDBGRDDATA_L 0x5207 Debug Data Read LS 32 Bits 0x0
IIRDBGRDDATA_H 0x5208 Debug Data Read MS 8 Bits 0x0
IIRCTL2 0x5210 Channel Control 0x0
IIIIR 0x5211 Input Data Index 0x0
IMIIR 0x5212 Input Data Modifier 0x0
ICIIR 0x5213 Input Data Count 0x0
IBIIR 0x5214 Input Data Base 0x0
OIIIR 0x5215 Output Data Index 0x0
OMIIR 0x5216 Output Data Modifier 0x0
OCIIR 0x5217 Output Data Count 0x0
OBIIR 0x5218 Output Data Base 0x0
CIIIR 0x5219 Coefficient Index 0x0
CMIIR 0x521A Coefficient Modifier 0x0
CCIIR 0x521B Coefficient Count 0x0
CPIIR 0x521C Chain Pointer 0x0
S/PDIF Transmit Registers
Register Mnemonic Address Description Reset
