Operation Modes

10-22 ADSP-214xx SHARC Processor Hardware Reference

Table 10-6. SPCTLx Control Bit Comparison

Bit Standard Serial

Mode

S and

Left-justified Mode

Packed Mode Multichannel Mode

Control

0 SPEN_A Reserved

1–2 DTYPE Reserved DTYPE

3 LSBF Reserved LSBF

4–8 SLEN

9 PACK

10 ICLK MSTR ICLK

11 OPMODE

12 CKRE Reserved CKRE

13 FSR Reserved

14 IFS Reserved IMFS

15 DIFS Reserved

16 LFS L_FIRST LMFS

17 LAFS OPMODE Reserved

18 SDEN_A

19 SCHEN_A

20 SDEN_B

21 SCHEN_B

22 FS_BOTH Reserved

23 BHD

24 SPEN_B Reserved

25 SPTRAN
