ADSP-214xx SHARC Processor Hardware Reference A-225
Registers Reference
010000 (0x10) TIMER0_O Timer0 Output
010001 (0x11) TIMER1_O Timer1 Output
010010 (0x12) Reserved
010011 (0x13) UART0_TX_O UART0 Transmitter Output
010100 (0x14) Reserved
010101 (0x15) SPI_MISO_O MISO from SPI
010110 (0x16) SPI_MOSI_O MOSI from SPI
010111 (0x17) SPI_CLK_O Clock Output from SPI
011000 (0x18) SPI_FLG0_O Slave Select 0 from SPI
011001 (0x19) SPI_FLG1_O Slave Select 1 from SPI
011010 (0x1A) SPI_FLG2_O Slave Select 2 from SPI
011011 (0x1B) SPI_FLG3_O Slave Select 3 from SPI
011100 (0x1C) SPIB_MISO_O MISO from SPIB
011101 (0x1D) SPIB_MOSI_O MOSI from SPIB
011110 (0x1E) SPIB_CLK_O Clock Output from SPIB
011111 (0x1F) SPIB_FLG0_O Slave Select 0 from SPIB
100000 (0x20) SPIB_FLG1_O Slave Select 1 from SPIB
100001 (0x21) SPIB_FLG2_O Slave Select 2 from SPIB
100010 (0x22) SPIB_FLG3_O Slave Select 3 from SPIB
100011 (0x23) FLAG4_O
Flag/PWM 4 Output
1
100100 (0x24) FLAG5_O Flag/PWM 5 Output
100101 (0x25) FLAG6_O Flag/PWM 6 Output
100110 (0x26) FLAG7_O Flag/PWM 7 Output
100111 (0x27) FLAG8_O Flag/PWM 8 Output
101000 (0x28) FLAG9_O Flag/PWM 9 Output
101001 (0x29) FLAG10_O Flag/PWM 10 Output
Table A-119. Group B Signals (Cont’d)
Binary Signal Description (Source Selection)
