ADSP-214xx SHARC Processor Hardware Reference 3-31
External Port
In Table 3-9,
SDADDRMODE = 1, X16DE = 1, SDRAW2–0 = 101 (13 bits), and
SDCAW = 10 (10 bits).
Table 3-9. Bank Interleaving Map (1K Page Size)
Pin Column Address Row Address Bank Address Pins of SDRAM
A[18] IA[10] BA[1]
A[17] IA[9] BA[0]
A[13]
A[12] IA[23] A[12]
A[11] IA[22] A[11]
SDA10 IA[21] A[10]
A[9] IA[8] IA[20] A[9]
A[8] IA[7] IA[19] A[8]
A[7] IA[6] IA[18] A[7]
A[6] IA[5] IA[17] A[6]
A[5] IA[4] IA[16] A[5]
A[4] IA[3] IA[15] A[4]
A[3] IA[2] IA[14] A[3]
A[2] IA[1] IA[13] A[2]
A[1] IA[0] IA[12] A[1]
A[0] 1/0 IA[11] A[0]
