ADSP-214xx SHARC Processor Hardware Reference A-11
Registers Reference
4DAIOFFShutdown Clock to DAI. Shutdown clock to DAI related
peripherals—SRU, SRC, S/PDIF, PCG, IDP, PDAP
0 = DAI is in normal mode
1 = Shutdown clock to DAI
5EPOFFShutdown Clock to External Port.
0 = External port is in normal mode
1 = Shutdown clock to external port
6SP01OFFShutdown Clock to SPORT 0, 1.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
7SP23OFFShutdown Clock to SPORT 2, 3.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
8SP45OFFShutdown Clock to SPORT 4, 5.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
9SP67OFFShutdown Clock to SPORT 6, 7.
0 = SPORTs in normal mode
1 = Shutdown clock to SPORTs
10 SP1OFF Shutdown Clock to SPI/SPIB.
0 = SPI in normal mode
1 = Shutdown clock to SPI
11 TMROFF Shutdown Clock to Peripheral Timer.
0 = Timer is in normal mode
1 = Shutdown clock to timer
12 LP0OFF Shutdown Clock to Link Port 0.
0 = LP0 is in normal mode
1 = Shutdown clock to LP0
13 LP1OFF Shutdown Clock to Link Port 1.
0 = LP1 is in normal mode
1 = Shutdown clock to LP1
15–14 Reserved
Table A-4. PMCTL1 Register Bit Descriptions (RW) (Cont’d)
Bit Name Description
