ADSP-214xx SHARC Processor Hardware Reference A-127
Registers Reference
001111 (0xF) DAI_PB16_O Pin Buffer 16
010000 (0x10) DAI_PB17_O Pin Buffer 17
010001 (0x11) DAI_PB18_O Pin Buffer 18
010010 (0x12) DAI_PB19_O Pin Buffer 19
010011 (0x13) DAI_PB20_O Pin Buffer 20
010100 (0x14) SPORT0_DA_O SPORT 0A Data
010101 (0x15) SPORT0_DB_O SPORT 0B Data
010110 (0x16) SPORT1_DA_O SPORT 1A Data
010111 (0x17) SPORT1_DB_O SPORT 1B Data
011000 (0x18) SPORT2_DA_O SPORT 2A Data
011001 (0x19) SPORT2_DB_O SPORT 2B Data
011010 (0x1A) SPORT3_DA_O SPORT 3A Data
011011 (0x1B) SPORT3_DB_O SPORT 3B Data
011100 (0x1C) SPORT4_DA_O SPORT 4A Data
011101 (0x1D) SPORT4_DB_O SPORT 4B Data
011110 (0x1E) SPORT5_DA_O SPORT 5A Data
011111 (0x1F) SPORT5_DB_O SPORT 5B Data
100000 (0x20) SRC0_DAT_OP_O SRC0 Data Out
100001 (0x21) SRC1_DAT_OP_O SRC1 Data Out
100010 (0x22) SRC2_DAT_OP_O SRC2 Data Out
100011 (0x23) SRC3_DAT_OP_O SRC3 Data Out
100100 (0x24) SRC0_TDM_IP_O SRC0 Data Out
100101 (0x25) SRC1_TDM_IP_O SRC1 Data Out
100110 (0x26) SRC2_TDM_IP_O SRC2 Data Out
100111 (0x27) SRC3_TDM_IP_O SRC3 Data Out
101000 (0x28) DIR_DAT_O SPDIF RX Serial Data Out
Table A-76. Group B Sources – Serial Data (Contd)
Selection Code Source Signal Description (Source Selection)
