DAI Signal Routing Unit Registers
A-126 ADSP-214xx SHARC Processor Hardware Reference
Figure A-64. SRU_DAT6 Register (RW)
Table A-76. Group B Sources – Serial Data
Selection Code Source Signal Description (Source Selection)
000000 (0x0) DAI_PB01_O Pin Buffer 1
000001 (0x1) DAI_PB02_O Pin Buffer 2
000010 (0x2) DAI_PB03_O Pin Buffer 3
000011 (0x3) DAI_PB04_O Pin Buffer 4
000100 (0x4) DAI_PB05_O Pin Buffer 5
000101 (0x5) DAI_PB06_O Pin Buffer 6
000110 (0x6) DAI_PB07_O Pin Buffer 7
000111 (0x7) DAI_PB08_O Pin Buffer 8
001000 (0x8) DAI_PB09_O Pin Buffer 9
001001 (0x9) DAI_PB10_O Pin Buffer 10
001010 (0xA) DAI_PB11_O Pin Buffer 11
001011 (0xB) DAI_PB12_O Pin Buffer 12
001100 (0xC) DAI_PB13_O Pin Buffer 13
001101 (0xD) DAI_PB14_O Pin Buffer 14
001110 (0xE) DAI_PB15_O Pin Buffer 15
Serial Port 7 Data
Channel A Input
SPORT7_DA_I
Serial Port 7 Data Channel BA Input
SPORT7_DB_I
Serial Port 6 Data Channel B Input
SPORT6_DB_I
Serial Port 6 Data
Channel A Input
SPORT6_DA_I
SPORT7_DA_I
Serial Port 7 Data Channel A Input
