ADSP-214xx SHARC Processor Hardware Reference A-139

Registers Reference

Figure A-76. SRU_EXT_MISCB Register (RW)

Table A-79. Group E Sources – Miscellaneous Signals

Selection Code Source Signal Description (Output Source Selection)

00000 (0x0) DAI_PB01_O Pin Buffer 1 Output

00001 (0x1) DAI_PB02_O Pin Buffer 2 Output

00010 (0x2) DAI_PB03_O Pin Buffer 3 Output

00011 (0x3) DAI_PB04_O Pin Buffer 4 Output

00100 (0x4) DAI_PB05_O Pin Buffer 5 Output

00101 (0x5) DAI_PB06_O Pin Buffer 6 Output

00110 (0x6) DAI_PB07_O Pin Buffer 7 Output

00111 (0x7) DAI_PB08_O Pin Buffer 8 Output

01000 (0x8) DAI_PB09_O Pin Buffer 9 Output

01001 (0x9) DAI_PB10_O Pin Buffer 10 Output

01010 (0xA) DAI_PB11_O Pin Buffer 11 Output

01011 (0xB) DAI_PB12_O Pin Buffer 12 Output

01100 (0xC) DAI_PB13_O Pin Buffer 13 Output

01101 (0xD) DAI_PB14_O Pin Buffer 14 Output

01110 (0xE) DAI_PB15_O Pin Buffer 15 Output

31 302928 27 26 25 24 23 22 21 20 19 18 17 16

09 837564 2114 12 11 101315

DAI Interrupt 24

DAI Interrupt 22

DAI Interrupt 23

DAI Interrupt 25

DAI_INT_25_I

DAI_INT_24_I

DAI_INT_23_I

DAI_INT_22_I

DAI Interrupt 25

DAI Interrupt 27

DAI Interrupt 26

DAI_INT_27_I

DAI_INT_26_I

DAI_INT_25_I
