DAI Signal Routing Unit Registers
A-140 ADSP-214xx SHARC Processor Hardware Reference
01111 (0xF) DAI_PB16_O Pin Buffer 16 Output
10000 (0x10) DAI_PB17_O Pin Buffer 17 Output
10001 (0x11) DAI_PB18_O Pin Buffer 18 Output
10010 (0x12) DAI_PB19_O Pin Buffer 19 Output
10011 (0x13) DAI_PB20_O Pin Buffer 20 Output
10100 (0x14) SPORT0_FS_O SPORT0 Frame Sync
10101 (0x15) SPORT1_FS_O SPORT1 Frame Sync
10110 (0x16) SPORT2_FS_O SPORT2 Frame Sync
10111 (0x17) SPORT3_FS_O SPORT3 Frame Sync
11000 (0x18) SPORT4_FS_O SPORT4 Frame Sync
11001 (0x19) SPORT5_FS_O SPORT5 Frame Sync
11010 (0x1A) DIT_BLKSTART_O S/PDIF TX Block Start Output
11011 (0x1B) PCG_FSA_O Precision Frame Sync A
11100 (0x1C) PCG_CLKB_O Precision Clock B
11101 (0x1D) PCG_FSB_O Precision Frame Sync B
11110 (0x1E) LOW Logic Level Low (0) as a Source
11111 (0x1F) HIGH Logic Level High (1) as a Source
Table A-79. Group E Sources – Miscellaneous Signals (Cont’d)
Selection Code Source Signal Description (Output Source Selection)
