DAI Signal Routing Unit Registers
A-144 ADSP-214xx SHARC Processor Hardware Reference
011010 (0x1A) SPORT4_DA_PBEN_O SPORT 4 Data Channel A Output Enable
011011 (0x1B) SPORT4_DB_PBEN_O SPORT 4 Data Channel B Output Enable
011100 (0x1C) SPORT5_CLK_PBEN_O SPORT 5 Clock Output Enable
011101 (0x1D) SPORT5_FS_PBEN_O SPORT 5 Frame Sync Output Enable
011110 (0x1E) SPORT5_DA_PBEN_O SPORT 5 Data Channel A Output Enable
011111 (0x1F) SPORT5_DB_PBEN_O SPORT 5 Data Channel B Output Enable
100000 (0x20) SPORT6_CLK_PBEN_O SPORT 6 Clock Output Enable
100001 (0x21) SPORT6_FS_PBEN_O SPORT 6 Frame Sync Output Enable
100010 (0x22) SPORT6_DA_PBEN_O SPORT 6 Data Channel A Output Enable
100011 (0x23) SPORT6_DB_PBEN_O SPORT 6 Data Channel B Output Enable
100100 (0x24) SPORT7_CLK_PBEN_O SPORT 7 Clock Output Enable
100101 (0x25) SPORT7_FS_PBEN_O SPORT 7 Frame Sync Output Enable
100110 (0x26) SPORT7_DA_PBEN_O SPORT 7 Data Channel A Output Enable
100111 (0x27) SPORT7_DB_PBEN_O SPORT 7 Data Channel B Output Enable
101000 (0x28) SPORT0_TDV_PBEN_O SPORT 0 Transmit Data Valid Output
101001 (0x29) SPORT1_TDV_PBEN_O SPORT 1 Transmit Data Valid Output
101010 (0x2A) SPORT2_TDV_PBEN_O SPORT 2 Transmit Data Valid Output
101011 (0x2B) SPORT3_TDV_PBEN_O SPORT 3 Transmit Data Valid Output
101100 (0x2C) SPORT4_TDV_PBEN_O SPORT 4 Transmit Data Valid Output
101101 (0x2D) SPORT5_TDV_PBEN_O SPORT 5 Transmit Data Valid Output
100111 (0x2E) SPORT6_TDV_PBEN_O SPORT 6 Transmit Data Valid Output
101110 (0x2F) SPORT7_TDV_PBEN_O SPORT 7 Transmit Data Valid Output
110000 (0x30)–1111111 (0x3F) Reserved
Table A-80. Group F Sources – Pin Output Enable (Cont’d)
