C613-50631-01 Rev A Command Reference for IE340 Series 1110
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
OSPF COMMANDS
AREA
RANGE
area range
Overview Use this command to summarize OSPF routes at an area boundary, configuring an
IPv4 address range which consolidates OSPF routes. By default, this feature is not
enabled.
A summary route created by this command is then advertised to other areas by the
Area Border Routers (ABRs). In this way, routing information is condensed at area
boundaries and outside the area so that routes are exchanged between areas in an
efficient manner.
If the network numbers in an area are arranged into sets of contiguous routes, the
ABRs can be configured to advertise a summary route that covers all the individual
networks within the area that fall into the specified range.
Use the cost parameter to specify a metric that will be advertised in the summary
Link State Advertisement (LSA), rather than relying on the standard method to
calculate the metric for the LSA.
The no variant of this command disables this function and restores default
behavior.
Syntax
area <area-id> range <ip-addr/prefix-length> [advertise] [cost
<0-16777215>]
area <area-id> range <ip-addr/prefix-length> not-advertise
no area <area-id> range <ip-addr/prefix-length>
Parameter Description
<area-id> The OSPF area that you summarizing the routes for.
Use one of the following formats: This can be entered
in either dotted decimal format or normal decimal
format.
<ip-addr> OSPF Area ID expressed in
IPv4 address format A.B.C.D.
<0-4294967295> OSPF Area ID expressed as a
decimal number within the
range shown.
For example the values dotted decimal 0.0.1.2 and
decimal 258 would both define the same area ID.
<ip-addr/prefix-
length>
The area range prefix and length.
advertise Advertise this range as a summary route into other
areas.
