C613-50631-01 Rev A Command Reference for IE340 Series 1553
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
BGP AND BGP4+ COMMANDS
SHOW
BGP IPV6 SUMMARY (BGP4+ ONLY)
show bgp ipv6 summary (BGP4+ only)
Overview Use this command to display a summary of a BGP4+ neighbor status within an IPv6
environment. Use the show ip bgp summary (BGP only) command to display a
summary of a BGP neighbor status within an IPv4 environment.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax
show bgp ipv6 summary
Mode User Exec and Privileged Exec
Example
awplus# show bgp ipv6 summary
Output Figure 30-5: Example output from the show ip bgp summary command
The Up/Down column in this output is a timer that shows:
• "never" if the peer session has never been established
• The up time, if the peer session is currently up
• The down time, if the peer session is currently down.
In the example above, the session with 2001:0db8:eeee::1 has been down for 4
seconds, and the session with 2001:0db8:dddd::1 has never been established.
Related
commands
show ip bgp summary (BGP only)
Command
changes
Added to AlliedWare Plus prior to 5.4.6-1
Version 5.4.7-2.1: BGP support added for x510 and x550 series
Version 5.4.7-2.4: BGP support added for IE300 series
awplus>show ip bgp summary

BGP router identifier 1.0.0.1, local AS number 65541
BGP table version is 12
4 BGP AS-PATH entries
0 BGP community entries

Neighbor V AS MsgRc MsgSnt TblVer InOutQ Up/Down State/PfxRcd
2001:0db8:cccc::1 4 65544 20 24 11 0/0 00:07:19 1
2001:0db8:dddd::1 4 65545 0 0 0 0/0 never Active
2001:0db8:eeee::1 4 65542 34 40 0 0/0 00:00:04 Active
2001:0db8:ffff::1 4 65543 29 32 11 0/0 00:07:03 13

Number of neighbors 4
