C613-50631-01 Rev A Command Reference for IE340 Series 2837
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
AMF AND AMF PLUS COMMANDS
ATMF
MANAGEMENT VLAN
atmf management vlan
Overview The AMF management VLAN is created when the AMF network is first initiated and
is assigned a default VID of 4092. This command enables you to change the VID
from this default value on this device.
The AMF management VLAN is one of AMF’s internal VLANs (the domain VLAN is
the other internal VLAN). AMF uses these internal VLANs to communicate network
status information between nodes. These VLANs must be reserved for AMF and not
used for other purposes.
CAUTION: Every member of your AMF network must have the same domain VLAN,
management VLAN, and management subnet.
CAUTION: If you change the domain VLAN, management VLAN, or management
subnet of a node, that change takes effect immediately and the node will immediately
leave the AMF network and try to rejoin it. The AMF network will not be complete until
you have given all devices the same setting, so they can all rejoin the AMF network.
Use the no variant of this command to restore the VID to the default of 4092.
Syntax
atmf management vlan <2-4090>
no atmf management vlan
Default VLAN 4092
Mode Global Configuration
Usage notes We recommend you only change the management VLAN when first creating the
AMF network, and only if VLAN 4092 is already being used in your network.
However, if you do need to change the VLAN on an existing AMF network, use the
following steps to ensure you change it on all nodes simultaneously:
1) Create a working set of the whole of your AMF network, using the
commands:
master# atmf working-set group all
You must use working-set group all if changing the management VLAN. If
you use a different working-set, nodes that are not in that working-set will
lose contact with the AMF network.
2) The prompt will display the number of nodes in the AMF network. Record
this number. In this example, the network is named “test” and has 10 nodes:
test[10]#
Parameter Description
<2-4090> The VID assigned to the AMF management VLAN.
