Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 366
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
CONNECTIVITY FAULT MANAGEMENT COMMANDS
ETHERNET
CFM MEP
ethernet cfm mep
Overview Use this command to create a Local MEP instance, or to enter Interface Ethernet
CFM MEP Configuration mode for an existing Local MEP's instance, so you can
configure it.
Use the no variant of this command to destroy the Local MEP instance.
Syntax
ethernet cfm mep down mpid <mep-id> domain-name <domain-name>
ma-name <ma-name>
no ethernet cfm mep down mpid <mep-id> domain-name <domain-name>
ma-name <ma-name>
Mode Interface Configuration
Usage notes Maintenance Points are entities that exist within an MD/MA and can perform the
CFM/802.1ag functions such as Continuity Checks for fault management. The main
type of MP is a Maintenance End Point (MEP). This type of maintenance point sits
at the edges of a Maintenance Domain but is a member of only one MA within the
Maintenance Domain. Thus an MEP is used at the end of a VLAN segment, or it is
used at the end of a link. MPs live on bridge ports and station ports. On a bridge
port, there are two types.
• An Up Maintenance Entity is considered an inward MP. It communicates
across the inside of the bridge to the other side, and this allows it to reach the
outside world. It lives on a bridge port for a given VLAN, but it does not use
this port to send or receive to get to the outside world. Instead, it sends and
receives through the inside of the bridge and communicates to the outside
world through the other VLAN port members. An Up MP cannot be used for
Link Level CFM.
• A Down Maintenance Entity is considered an outward MP. It sends and
receives only through its bridge port outwardly to the outside world, and
does not communicate inside the bridge. A Down MP is not subject to
blocking due to Spanning Tree Protocol (STP) or any other protocol trying to
Parameter Description
down Specify the Local MEP as a Down MEP.
mpid Specify the Local MEP ID.
<mep-id> 1-8191. This must be unique ID for all MEPs in the MA (both local
and remote).
domain-name Specify the Maintenance Domain that the Local MEP is to be
associated with.
<domain-name> Specify the Maintenance Domain's CLI instance name.
ma-name Specify the Maintenance Association that the Local MEP is to be
associated with.
<ma-name> Specify the Maintenance Association's CLI instance name.
