Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 1930
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
PIM-DM COMMANDS
SHOW
IP PIM DENSE-MODE INTERFACE
show ip pim dense-mode interface
Overview This command displays the PIM-DM interface information.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax
show ip pim dense-mode interface
Mode User Exec and Privileged Exec
Example To display information about the PIM-DM interfaces, use the command:
awplus# show ip pim dense-mode interface
Output
Total configured interfaces: 24 Maximum allowed: 32
Total active interfaces: 22

Address Interface VIFIndex Ver/ Nbr
Mode Count
192.168.1.53/24 vlan2 0 v2/D 2
192.168.2.1 vlan3 2 v2/D 0
...
Note that this screen has been edited to remove any additional 
interfaces.
Table 1: Parameters in the output of the show ip pim dense-mode interface
command
Parameter Description
Total configured
interfaces
The number of configured PIM Dense Mode interfaces.
Maximum allowed The maximum number of PIM Dense Mode interfaces that
can be configured.
Total active
interfaces
The number of active PIM Dense Mode interfaces.
Address Primary PIM-DM address.
Interface Name of the PIM-DM interface.
VIF Index The Virtual Interface index of the VLAN.
Ver/Mode PIM version/Dense mode.
Nbr Count Neighbor count of the PIM-DM interface.
