Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 3014
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
AMF AND AMF PLUS COMMANDS
SHOW
ATMF VIRTUAL-LINKS
show atmf virtual-links
Overview This command displays a summary of all virtual links (L2TP tunnels) currently in the
running configuration.
Syntax
show atmf virtual-links [macaddr]
show atmf virtual-links [id <1-4094>] [remote-id <1-4094>]
show atmf virtual-links detail [id <1-4094>]
Mode Privileged Exec
Example 1 To display AMF virtual links, use the command:
node_1# show atmf virtual-links
In the above example, a centrally located switch has the IP address space
192.0.2.x/24. It has two VLANs assigned the subnets 192.0.2.33 and 192.0.2.65
using the prefix /27. Each subnet connects to a virtual link. The first link has the IP
address 192.168.1.1 and has a Local ID of 1. The second has the IP address
192.168.2.1 and has the Local ID of 2.
Example 2 To display details about AMF virtual link with ID 1, use the command:
node_1# show atmf virtual-links detail id 1
Parameter Description
macaddr Display the virtual AMF links’ MAC addresses.
id <1-4094> ID of the local virtual link.
remote-id <1-4094> ID of the remote virtual link
detail Display information about a specific virtual link ID or range
of virtual link IDs. Displays information such as: local and
remote IP address, link type, packets received and
transmitted.
Table 57-1: Example output from show atmf virtual-links
ATMF Virtual-Link Information:

Local Local Remote Tunnel Tunnel
Port ID IP ID IP Protect State
------------------------------------------------------------------------
vlink1 1 172.16.24.2 2 1.0.0.2 - Complete
vlink2 2 172.16.24.2* 10 172.16.24.3* ipsec Complete
vlink3 3 (eth0)* 1 1.2.3.4 - AcquireLocal

* = Dynamic Address.

Virtual Links Configured: 3
