C613-50631-01 Rev A Command Reference for IE340 Series 353
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
PLUGGABLES AND CABLING COMMANDS
TEST
CABLE-DIAGNOSTICS TDR INTERFACE
test cable-diagnostics tdr interface
Overview Use this command to apply the Cable Fault Locator’s cable-diagnostics tests to
twisted pair data cables for a selected port. The tests will detect either correct,
short circuit, or open, circuit terminations. For more information on running the
CFL, see the Pluggables and Cabling Feature Overview and Configuration Guide.
The test can take several seconds to complete. See the related show command to
display the test results.
A new test can only be started if no other test is in progress. CFL cannot run on a
port that is currently supplying power via PoE.
The displayed status of the cable can be either, OK, Short (within-pair), or Open.
The “Open” or “Short” status is accompanied with the distance from the source
port to the incorrect termination.
Syntax
test cable-diagnostics tdr interface <interface>
Mode Privileged Exec
Example To run a cable test on the cable inserted into port1.0.1 use the following command:
awplus# test cable-diagnostics tdr interface port1.0.1
You will receive the following message:
Link will go down while test is in progress. Continue? (y/n): y
Select y to continue.
awplus# y
You will then receive the following message:
Test started. This will take several seconds to complete. Use
"show test cable-diagnostics tdr" to print results.
Related
commands
clear test cable-diagnostics tdr
show test cable-diagnostics tdr
Parameter Description
cable-diagnostics The cable diagnostic tests.
tdr Time Domain Reflectometry.
interface Selects the interface to test.
<interface> Interface number of the port to be tested, e.g. port1.0.2.
