Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 2696
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
ETHERNET PROTECTION SWITCHED RING (EPSRING™) COMMANDS
SHOW
EPSR SUMMARY
show epsr summary
Overview This command displays summary information about all EPSR instances on the
switch
Syntax
show epsr summary
Mode User Exec and Privileged Exec
Example To display EPSR summary information, use the command:
awplus# show epsr summary
Table 55: Example output from the show epsr summary command
EPSR Summary Information

Abbreviations:
M = Master node
T = Transit node
C = is on a common segment with other instances
P = instance on a common segment has physical control of the shared port's
data VLAN blocking
LB = ring port is Logically Blocking - applicable to master only

EPSR Ctrl Primary/1st Secondary/2nd
Instance Mode Status State VLAN Prio Port Status Port Status
--------------------------------------------------------------------------------
test-12345 T Enabled Links-Down 6 127 Blocking (C,P) Blocking (C,P)
test1 M Enabled Complete 5 12 Fwding Fwding (LB)
test2 T Enabled Pre-Fwding 4 126 Fwding (C) Blocking (C)
localB T Disabled Idle 40 0 Unknown Unknown
localC T Disabled Idle 41 0 Unknown Unknown
--------------------------------------------------------------------------------
