C613-50631-01 Rev A Command Reference for IE340 Series 2787
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
AMF AND AMF PLUS COMMANDS
ATMF
-AREALINK
atmf-arealink
Overview This command to enable an Eth interface, on an AR-series device, as an AMF area
link. AMF area links are designed to operate between two nodes in different areas
in an AMF network. This command is only available if your network is running in
AMF secure mode (see atmf secure-mode for more information on AMF secure
mode).
Use the no variant of this command to remove any AMF area links that may exist
for the selected Eth interface.
Syntax
atmf-arealink remote-area <area-name> vlan <2-4094>
no atmf-arealink
Default By default, no area links are configured
Mode Eth interface on an AR-series device.
Usage notes Run this command on the interface at both ends of the link.
Each area must have the area-name configured, and the same area password must
exist on both ends of the link.
Running this command will synchronize the area information stored on the two
nodes.
You can configure multiple area links between two area nodes, but only one area
link at any time will be in use. All other area links will block information, to prevent
network storms.
NOTE: See the switchport atmf-arealink command to configure an AMF area link on an
a switch port or link aggregator
Example To configure eth1 as an AMF area link to the ‘Auckland’ area on VLAN 6, use the
following commands:
master_1# configure terminal
master_1(config)# interface eth1
master_1(config-if)# atmf-arealink remote-area Auckland vlan 6
To remove eth1 as an AMF area link, use the following commands:
master_1# configure terminal
master_1(config)# interface eth1
master_1(config-if)# no atmf-arealink
Parameter Description
<area-name> The name of the remote area that the interface is connecting to.
<2-4094> The VLAN ID for the link. This VLAN cannot be used for any other
purpose, and the same VLAN ID must be used at each end of the link.
