C613-50631-01 Rev A Command Reference for IE340 Series 2720
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
G.8032 ETHERNET RING PROTECTION SWITCHING COMMANDS
PHYSICAL
-RING
physical-ring
Overview Use this command to specify which G.8032 physical ring instance is to be used by
this G.8032 Ethernet Ring Protection (ERP) instance.
Syntax
physical-ring <physical-ring-name>
Mode G8032 Configure Switch
Usage notes A G.8032 ERP instance in general has two ring ports, unless it is at the end of a
sub-ring in which case it has only one ring port. Ring port(s) are specified using a
G.8032 physical ring instance.
This command can only be accepted when the ERP instance is disabled.
Example To configure an ERP instance named “blue” to use a physical ring instance named
“red”, use the following commands:
awplus(config)# g8032 erp-instance blue
awplus(g8032-config-switch)# physical-ring red
Related
commands
g8032 erp-instance
g8032 physical-ring
show g8032 erp-instance
Command
changes
Version 5.4.7-0.1: command added
Version 5.4.7-1.1: added to x310 series products
Version 5.4.7-2.1: added to x550 series products
Version 5.4.8-0.2: added to SBx8100 series products
Version 5.4.8-1.1: added to SBx908 GEN2 series products
Parameter Description
<physical-ring-name> The name of the physical ring instance.
