C613-50631-01 Rev A Command Reference for IE340 Series 2765
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
MEDIA REDUNDANCY PROTOCOL (MRP) COMMANDS
VLAN
-ID (MRP-RING)
vlan-id (mrp-ring)
Overview Use this command to assign a VLAN to an MRP ring.
Syntax
vlan-id <vlan>
Mode MRP Ring Configuration
Usage notes This is only possible if the ports attached to the MRP ring are set to trunked mode.
In access mode, MRP will automatically set this to the VLAN of the port.
Both ports must be in the same VLAN.
Example To assign VLAN 2 to MRP ring 1, use the commands:
awplus# configure terminal
awplus(config)# mrp ring 1
awplus(config-mrp-ring)# vlan-id 2
Related
commands
domain-id (mrp-ring)
domain-name (mrp-ring)
enable (mrp-ring)
mrp ring
profile (mrp-ring)
role (mrp-ring)
Command
changes
Version 5.5.0-2.1: command added
Parameter Description
<vlan> <1-4094> The ID of the VLAN to be assigned.
