C613-50631-01 Rev A Command Reference for IE340 Series 2764
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
MEDIA REDUNDANCY PROTOCOL (MRP) COMMANDS
SHOW
MRP RING
Related
commands
mrp ring
Command
changes
Version 5.5.0-2.1: command added
Table 56-4: Parameters in the output from show mrp ring
Parameter Description
Domain ID The UUID that identifies the ring.
The Domain ID is used in MRP PDU packets.
Domain Name Description of the ring that can be set by the user.
Ring Status Whether the ring is Enabled or Disabled.
Operating Mode CLI - the MRP ring is configured and controlled from the
command line.
Role Whether the node is a Manager (MRM) or Client (MRC).
Network Status Whether the MRP ring is Open or Closed (MRM only).
Port Status The state of the port:
Disabled - all packets received by the port are dropped.
Blocking - all packets received by the port are dropped,
with the exception of MRP protocol packets.
Forwarding - all packets received by the port are
forwarded.
Vlan ID If the MRP ring is configured with a trunked VLAN, this
shows the configured VLAN ID.
Profile Whether it is configured for 200ms or 500ms.
