C613-50631-01 Rev A Command Reference for IE340 Series 523
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
PORT MIRRORING AND REMOTE MIRRORING COMMANDS
SHOW
REMOTE-MIRROR
show remote-mirror
Overview Use this command to display information for remote-mirroring.
Syntax
show remote-mirror
Mode User Exec
Example To display information about remote mirroring, use the command:
awplus# show remote-mirror
Output Figure 13-3: Example output from show remote-mirror
awplus#show remote-mirror
Remote mirror information:
Remote mirror destination:
Port: port1.0.3
VLAN: 259
User priority: 0
Monitored ports:
port1.0.1
direction: both
Remote mirror egress ports:
Remote mirror VLANs:
VLAN 259
Table 13-1: Parameters in the output from show remote-mirror
Parameter Description
Remote mirror
destination
On the source device, this displays information about:
• the egress port for the mirrored traffic on the source
device
• the remote mirroring VLAN ID this traffic is tagged with
on egress
• the user priority this traffic is tagged with on egress
Monitored ports On the source device, this displays:
• the ports being mirrored (monitored)
• the direction—whether both received traffic,
transmitted traffic or both are mirrored
• ‘none (via ACL)’ if it is configured with the command
remote-mirror interface none to allow ACLs to select
the traffic to be mirrored
