Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 1741
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
MLD AND MLD SNOOPING COMMANDS
SHOW
IPV6 MLD GROUPS
show ipv6 mld groups
Overview Use this command to display the multicast groups that have receivers directly
connected to the router and learned through MLD.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Syntax
show ipv6 mld groups [<ipv6-address>|<interface>] [detail]
Mode User Exec and Privileged Exec
Examples The following command displays local-membership information for all interfaces:
awplus# show ipv6 mld groups
Output Figure 33-2: Example output for show ipv6 mld groups
The following command displays local-membership information for all interfaces:
awplus# show ipv6 mld groups detail
Figure 33-3: Example output for show ipv6 mld groups detail
Parameter Description
<ipv6-address> Optional. Specify Address of the multicast group in format
X:X::X:X.
<interface> Optional. Specify the Interface name for which to display local
information.
awplus#show ipv6 mld groups
MLD Connected Group Membership
Group Address Interface Uptime Expires Last Reporter 
ff08::1 vlan10 (port1.0.1) 00:07:27 00:03:10 fe80::200:1ff:fe20:b5ac
awplus# show ipv6 mld groups detail
MLD Connected Group Membership Details for port1.0.1 
Interface: port1.0.1 
Group: ff08::1 
Uptime: 00:00:13 
Group mode: Include () 
Last reporter: fe80::eecd:6dff:fe6b:4783 
Group source list: (R - Remote, M - SSM Mapping, S - Static ) 
Source Address Uptime v2 Exp Fwd Flags 
2001:db8::1 00:00:13 00:04:07 Yes R 
2002:db8::3 00:00:13 00:04:07 Yes R
