Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 1829
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
PIM-SM COMMANDS
SHOW
IP PIM SPARSE-MODE INTERFACE
show ip pim sparse-mode interface
Overview Use this command to show PIM-SM interface information.
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide
Syntax
show ip pim sparse-mode interface
Mode User Exec and Privileged Exec
Example To display information about PIM-SM interfaces, use the command:
awplus# show ip pim sparse-mode interface
Output Figure 35-6: Example output from show ip pim sparse-mode interface
Total configured interfaces: 100 Maximum allowed: 100
Total active interfaces: 100

Address Interface VIFindex Ver/ Nbr DR DR
Mode Count Prior
10.1.100.4 vlan100 4 v2/S 2 1 10.1.100.6
10.2.101.10 vlan1001 5 v2/S 0 1 10.2.101.10
10.2.102.10 vlan1002 6 v2/S 0 1 10.2.102.10
10.2.103.10 vlan1003 7 v2/S 0 1 10.2.103.10
10.2.104.10 vlan1004 8 v2/S 0 1 10.2.104.10
10.2.105.10 vlan1005 9 v2/S 0 1 10.2.105.10
10.2.106.10 vlan1006 10 v2/S 0 1 10.2.106.10
10.2.107.10 vlan1007 11 v2/S 0 1 10.2.107.10
...
Table 1: Parameters in the output from the show ip pim sparse-mode interface
command
Parameters Description
Total configured
interfaces
The number of configured PIM Sparse Mode interfaces.
Maximum allowed The maximum number of PIM Sparse Mode interfaces that
can be configured.
Total active
interfaces
The number of active PIM Sparse Mode interfaces.
Address Primary PIM-SM address.
Interface Name of the PIM-SM interface.
VIF Index The Virtual Interface index of the interface.
