MEDIA REDUNDANCY PROTOCOL (MRP) COMMANDS
SHOW
COUNTER MRP
show counter mrp
Overview Use this command to show the MRP counters.
The global counters provide an overall count of protocol packets being sent and
received, as well as the timer and dispatcher that show the service has not halted.
The ring counters provide per-ring counters for both ring ports. These count the
different types of MRP PDU packets that are sent and received. They also provide
topology and port state counters that record events on the ring.
Syntax
show counter mrp [global|ring <ring-id>]
Mode User Exec
Example To show all MRP counters, use the command:
awplus# show counter mrp
To show only the global MRP counters, use the command:
awplus# show counter mrp global
To show all MRP counters for MRP ring 1, use the command:
awplus# show counter mrp ring 1
Output Figure 56-1: Example output from show counter mrp
Parameter Description
global Show only global MRP counters.
ring Show only MRP counters for a specific MRP ring.
<ring-id> <1-65535>. The ID of an MRP ring.
awplus#show counter mrp
Media Redundancy Protocol Global Counters

MRP Started ....... 2
MRP Dispatcher ....... 19102219
MRP Timer Tick ....... 17373917
MRP Packet RX ....... 1728302
MRP Packet RX Error ....... 0
MRP Packet TX ....... 1728303
MRP Packet TX Error ....... 0

Media Redundancy Protocol Ring 1 Counters

Port 1 PDUs Received
MRP_Test ......... 864150
MRP_TopologyChange ......... 0
MRP_LinkUp ......... 0
MRP_LinkDown ......... 0
