Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 1957
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
IPV4 HARDWARE ACCESS CONTROL LIST (ACL) COMMANDS
ACCESS
-LIST (NUMBERED HARDWARE ACL FOR MAC ADDRESSES)
Mode Global Configuration
Default On an interface controlled by a hardware ACL, any traffic that does not explicitly
match a filter is permitted.
Usage notes This command creates an ACL for use with hardware classification. Once you have
configured the ACL, use the access-group or the match access-group command to
apply this ACL to a port, VLAN or QoS class-map.
ACLs numbered in the range 4000-4699 match on packets that have the specified
source and destination MAC addresses.
Examples To create an access-list that will permit packets with a source MAC address of
0000.00ab.1234 and any destination address, use the commands:
awplus# configure terminal
awplus(config)# access-list 4000 permit 0000.00ab.1234
0000.0000.0000 any
Parameter Description
<4000-4699> An ID number for this hardware IP access-list.
<action> The action that the switch will take on matching packets. See the
table above for valid values.
<source-mac> The source MAC address to match against, followed by the mask.
Enter the address in the format <HHHH.HHHH.HHHH>, where each
H is a hexadecimal number.
Enter the mask in the format <HHHH.HHHH.HHHH>, where each H
is a hexadecimal number. For a mask, each value is either 0 or F,
where FF = Ignore, and 00 = Match.
any Match against any source MAC address.
<dest-mac> The destination MAC address to match against, followed by the
mask.
Enter the address in the format <HHHH.HHHH.HHHH>, where each
H is a hexadecimal number.
Enter the mask in the format <HHHH.HHHH.HHHH>, where each H
is a hexadecimal number. For a mask, each value is either 0 or F,
where FF = Ignore, and 00 = Match.
any Match against any destination MAC address.
vlan <1-4094> Match against the specified ID in the packet’s VLAN tag.
inner-vlan
<1-4094>
Match against the inner VLAN tag (VID). This parameter is used
within double-tagged VLANs. It is sometimes referred to as the
C-TAG (Customer VLAN TAG), where the vlan VID tag is referred to as
the S-TAG (Service VLAN TAG).
