C613-50631-01 Rev A Command Reference for IE340 Series 3458
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
PROFINET COMMANDS
SHOW
PROFINET ALARM
Related
commands
show profinet status
Command
changes
Version 5.5.2-1.6 and 5.5.3-0.1: command added
Table 70-1: Parameters in the output from show profinet alarm
Parameter Description
USI User Structure Identifier: Defines the format of the alarm.
Within Diagnostic Alarms, there are two formats that are
differentiated by their USI, the Standard Format and a User
Defined Format.
Channel Corresponds to which sensor it is and its order in the
GSDML file:
Channel 0x0001 - System temperature
Channel 0x0002 - Power supply input 1 voltage
Channel 0x0003 - Power supply input 2 voltage
Channel 0x0004 - External alarm LED output
Channel 0x0005 - External contact input
Channel 0x0006 - Power supply input 1
Channel 0x0007 - Power supply input 2
Ch.error Channel error: Signifies what the alarm reason is as
defined in PROFINET standards. These values correspond
to items such as OK, Fault, Open, Closed, Yes, No, Over
voltage etc.
For example: A ChannelError ‘Fault’
Ext.error Extended error: The extended channel error information.
Add.value Additional value: The sensor reading.
