ROUTING COMMANDS
SHOW
IP ROUTE
• next hop IP address
• outgoing interface name
• time since route entry was added
Figure 25-2: Example output from the show ip route command
Connected Route An example of a connected route entry consists of:
This route entry denotes:
• Route entries for network 10.10.31.0/24 are derived from the IP address of
local interface vlan2.
• These routes are marked as Connected routes (C) and always preferred over
routes for the same network learned from other routing protocols.
OSPF Route An example of an OSPF route entry consists of:
This route entry denotes:
• This route in the network 10.10.37.0/24 was added by OSPF.
• This route has an administrative distance of 110 and metric/cost of 11.
• This route is reachable via next hop 10.10.31.16.
• The outgoing local interface for this route is vlan2.
• This route was added 20 minutes and 54 seconds ago.
OSPF External
Route
An example of an OSPF external route entry consists of:
This route entry denotes that this route is the same as the other OSPF route
explained above; the main difference is that it is a Type 2 External OSPF route.
Codes: C - connected, S - static, R - RIP, B - BGP
O - OSPF, IA - OSPF inter area
N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
E1 - OSPF external type 1, E2 - OSPF external type 2
* - candidate default

O 10.10.37.0/24 [110/11] via 10.10.31.16, vlan2, 00:20:54
C 3.3.3.0/24 is directly connected, vlan1
C 10.10.31.0/24 is directly connected, vlan2
C 10.70.0.0/24 is directly connected, vlan4
O E2 14.5.1.0/24 [110/20] via 10.10.31.16, vlan2, 00:18:56
C 33.33.33.33/32 is directly connected, lo
C 10.10.31.0/24 is directly connected, vlan2
O 10.10.37.0/24 [110/11] via 10.10.31.16, vlan2, 00:20:54
O E2 14.5.1.0/24 [110/20] via 10.10.31.16, vlan2, 00:18:56
