IPV4 HARDWARE ACCESS CONTROL LIST (ACL) COMMANDS
ACCESS
-LIST (NUMBERED HARDWARE ACL FOR IP PROTOCOLS)
<ip-addr>
<reverse-mask>
Match any destination IP address
within the specified subnet. Specify
the subnet by entering a reverse
mask in dotted decimal format. For
example, entering “192.168.1.1
0.0.0.255” is the same as entering
192.168.1.1/24.
vlan <1-4094> The VLAN to match against. The ACL will match against the
specified ID in the packet’s VLAN tag.
Table 38-4: IP protocol number and description
Protocol Number Protocol Description [RFC]
1 Internet Control Message [RFC792]
2 Internet Group Management [RFC1112]
3 Gateway-to-Gateway [RFC823]
4 IP in IP [RFC2003]
5 Stream [RFC1190] [RFC1819]
6 TCP (Transmission Control Protocol) [RFC793]
8 EGP (Exterior Gateway Protocol) [RFC888]
9 IGP (Interior Gateway Protocol) [IANA]
11 Network Voice Protocol [RFC741]
17 UDP (User Datagram Protocol) [RFC768]
20 Host monitoring [RFC869]
27 RDP (Reliable Data Protocol) [RFC908]
28 IRTP (Internet Reliable Transaction Protocol) [RFC938]
29 ISO-TP4 (ISO Transport Protocol Class 4) [RFC905]
30 Bulk Data Transfer Protocol [RFC969]
33 DCCP (Datagram Congestion Control Protocol) [RFC4340]
48 DSR (Dynamic Source Routing Protocol) [RFC4728]
50 ESP (Encap Security Payload) [RFC2406]
51 AH (Authentication Header) [RFC2402]
54 NARP (NBMA Address Resolution Protocol) [RFC1735]
58 ICMP for IPv6 [RFC1883]
59 No Next Header for IPv6 [RFC1883]
60 Destination Options for IPv6 [RFC1883]
Table 38-3: Parameters in access-list (hardware IP numbered) (cont.)
Parameter Description
