C613-50631-01 Rev A Command Reference for IE340 Series 1974
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
IPV4 HARDWARE ACCESS CONTROL LIST (ACL) COMMANDS
(NAMED HARDWARE ACL ENTRY FOR ICMP)
send-to-vlan-port
vlan <vid> port
<port-number>
Send matching packets to the specified port, tagged with
the specified VLAN. The specified port must belong to the
specified VLAN.
send-to-cpu Send matching packets to the CPU.
Parameter Description
<sequence-
ď€
number>
The sequence number for the filter entry of the selected access
control list, in the range 1-65535. If you do not specify a
sequence number, the switch puts the entry at the end of the
ACL and assigns it the next available multiple of 4 as its
sequence number.
<action> The action that the switch will take on matching packets. See
the table above for valid values.
icmp Match against ICMP packets
<source-ip> The source addresses to match against. You can specify a single
host, a subnet, or all source addresses. The following are the
valid formats for specifying the source:
any Match any source IP address.
host <ip-addr> Match a single source host with the
IP address given by <ip-addr> in
dotted decimal notation.
<ip-addr>/<prefix> Match any source IP address within
the specified subnet. Specify the
subnet by entering the IPv4
address, then a forward slash, then
the prefix length.
<ip-addr>
<reverse-mask>
Match any source IP address within
the specified subnet. Specify the
subnet by entering a reverse mask
in dotted decimal format. For
example, entering “192.168.1.1
0.0.0.255” is the same as entering
192.168.1.1/24.
<dest-ip> The destination addresses to match against. You can specify a
single host, a subnet, or all destination addresses. The following
are the valid formats for specifying the destination:
any Match any destination IP address.
host <ip-addr> Match a single destination host
with the IP address given by
<ip-addr> in dotted decimal
notation.
V
alues for the <action> parameter
