C613-50631-01 Rev A Command Reference for IE340 Series 2017
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
IPV4 SOFTWARE ACCESS CONTROL LIST (ACL) COMMANDS
(ACCESS-LIST EXTENDED ICMP FILTER)
Mode IPv4 Extended ACL Configuration
Default Any traffic controlled by a software ACL that does not explicitly match a filter is
denied.
Usage notes An ACL can be configured with multiple ACL filters using sequence numbers. If the
sequence number is omitted, the next available multiple of 4 will be used as the
sequence number for the new filter. A new ACL filter can be inserted into the
middle of an existing list by specifying the appropriate sequence number.
NOTE: The access control list being configured is selected by running the access-list
(extended numbered) command or the access-list extended (named) command, with
the required access control list number, or name - but with no further parameters
selected.
Software ACLs will deny access unless explicitly permitted by an ACL action.
Examples To add a new entry in access-list called ‘my-list’ that will reject ICMP packets from
10.0.0.1 to 192.168.1.1, use the commands:
awplus# configure terminal
awplus(config)# access-list extended my-list
awplus(config-ip-ext-acl)# deny icmp 10.0.0.1/32 192.168.1.1/32
Use the following commands to add a new filter at sequence number 5 position of
the access-list called ‘my-list’. The filter will accept the ICMP type 8 packets from
10.1.1.0/24 network, to 192.168.1.0 network:
awplus# configure terminal
awplus(config)# access-list extended my-list
awplus(config-ip-ext-acl)# 5 permit icmp 10.1.1.0/24
192.168.1.0/24 icmp-type 8
Related
commands
access-group
show interface access-group
show running-config
show ip access-list
icmp-type The ICMP type.
<icmp-value> The value of the ICMP
type.
log Log the results.
Parameter Description
