C613-50631-01 Rev A Command Reference for IE340 Series 2063
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
IPV6 HARDWARE ACCESS CONTROL LIST (ACL) COMMANDS
(NAMED IPV6 HARDWARE ACL: ICMP ENTRY)
Mode IPv6 Hardware ACL Configuration (accessed by running the command ipv6
access-list (named IPv6 hardware ACL))
Default On an interface controlled by a hardware ACL, any traffic that does not explicitly
match a filter is permitted.
Usage notes To use this command, first run the command ipv6 access-list (named IPv6
hardware ACL) and enter the desired access-list name. This changes the prompt to:
awplus(config-ipv6-hw-acl)#
Then use this command (and the other “named IPv6 hardware ACL: entry”
commands) to add filter entries. You can add multiple filter entries to an ACL.
If you specify a sequence number, the new entry is inserted at the specified
location. If you do not specify a sequence number, the switch puts the entry at the
end of the ACL and assigns it the next available multiple of 4 as its sequence
number.
Once you have configured the ACL, use the ipv6 traffic-filter or the match
access-group command to apply this ACL to a port, VLAN or QoS class-map. Note
that the ACL will only apply to incoming data packets.
host
<ipv6-dest-host>
Match a single destination host
address.
The IPv6 address uses the format
X:X::X:X.
icmp-type
<number>
The type of ICMP message to match against, as defined in RFC792
and RFC950. Values include:
0 Echo replies.
3 Destination unreachable
messages.
4 Source quench messages.
5 Redirect (change route) messages.
8 Echo requests.
11 Time exceeded messages.
12 Parameter problem messages.
13 Timestamp requests.
14 Timestamp replies.
15 Information requests.
16 Information replies.
17 Address mask requests.
18 Address mask replies.
vlan <1-4094> The VLAN to match against. The ACL will match against the
specified ID in the packet’s VLAN tag.
Parameter Description
