Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 2076
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
IPV6 HARDWARE ACCESS CONTROL LIST (ACL) COMMANDS
(NAMED IPV6 HARDWARE ACL: TCP OR UDP ENTRY)
Mode IPv6 Hardware ACL Configuration (accessed by running the command ipv6
access-list (named IPv6 hardware ACL))
Default On an interface controlled by a hardware ACL, any traffic that does not explicitly
match a filter is permitted.
Usage notes To use this command, first run the command ipv6 access-list (named IPv6
hardware ACL) and enter the desired access-list name. This changes the prompt to:
awplus(config-ipv6-hw-acl)#
Then use this command (and the other “named IPv6 hardware ACL: entry”
commands) to add filter entries. You can add multiple filter entries to an ACL.
If you specify a sequence number, the new entry is inserted at the specified
location. If you do not specify a sequence number, the switch puts the entry at the
any Match any destination IP address.
host <ip-addr> Match a single destination host with
the IP address given by <ip-addr> in
dotted decimal notation.
<ip-addr>/
<prefix>
Match any destination IP address
within the specified subnet. Specify
the subnet by entering the IPv4
address, then a forward slash, then
the prefix length.
<ip-addr>
<reverse-mask>
Match any destination IP address
within the specified subnet. Specify
the subnet by entering a reverse
mask in dotted decimal format. For
example, entering “192.168.1.1
0.0.0.255” is the same as entering
192.168.1.1/24.
<dest-ports> Match destination TCP or UDP port numbers. Port numbers are
specified as integers between 0 and 65535. You can specify one or
more port numbers as follows:
eq <0-65535> Match a single port number.
lt <0-65535> Match all port numbers that are less
than the specified port number.
gt <0-65535> Match all port numbers that are
greater than the specified port
number.
ne <0-65535> Match all port numbers except the
specified port number.
range <start-port>
<end-port>
Match a range of port numbers.
vlan <1-4094> The VLAN to match against. The ACL will match against the
specified ID in the packet’s VLAN tag.
Parameter Description
