C613-50631-01 Rev A Command Reference for IE340 Series 2248
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
AUTHENTICATION COMMANDS
AUTH
SUPPLICANT-MAC
Default No supplicant MAC address for port authentication exists by default until first
created with the auth supplicant-mac command. The defaults for parameters are
shown in the table above.
Mode Interface Configuration for a static channel, a dynamic (LACP) channel group, or a
switch port; or Authentication Profile mode.
Examples To add the supplicant MAC address 0000.5E00.5343 to force authorized port
control for interface port1.0.2, use the commands:
awplus# configure terminal
awplus(config)# interface port1.0.2
awplus(config-if)# auth supplicant-mac 0000.5E00.5343
port-control force-authorized
To apply the mask ffff.ff00.0000 in order to add any supplicant MAC addresses
whose MAC address begins with 0000.5E, and then to force authorized port control
for interface port1.0.2, use the commands:
awplus# configure terminal
awplus(config)# interface port1.0.2
awplus(config-if)# auth supplicant-mac 0000.5E00.0000 mask
ffff.ff00.0000 port-control force-authorized
To delete the supplicant MAC address 0000.5E00.5343 for interface port1.0.2, use
the commands:
awplus# configure terminal
awplus(config)# interface port1.0.2
awplus(config-if)# no auth supplicant-mac 0000.5E00.5343
To disable reauthentication for the supplicant MAC address 0000.5E00.5343 for
interface port1.0.2, use the commands:
awplus# configure terminal
awplus(config)# interface eth1
awplus(config-if)# no auth supplicant-mac 0000.5E00.5343
reauthentication
<1-65535> Seconds for supplicant response timeout.
server-timeout Authentication server response timeout (default 30
seconds).
<1-65535> Seconds for authentication server response timeout.
reauthentication Enable reauthentication on a port.
max-reauth-req No of reauthentication attempts before becoming
unauthorized (default 2).
<1-10> Count of reauthentication attempts.
Parameter Description
